The core of the i.MX285 is Our fast, proven, power-efficient implementation of the Arm926EJ-S™ core, with speeds of up to 454 MHz. With attention to overall system cost, i.MX28 integrates physical USB interfaces (PHY), a 10/100 Ethernet, power management, and a resistive touch screen display controller. This processor with full AEC –Q100 automotive qualification is ideal for automotive infotainment systems featuring display and touch screen control systems. As a result, the i.MX285 enables many of the features only available in high-end systems, but at a price point suitable for all vehicles.
Multimedia Applications Processors - Automotive Applications, Connectivity, Integration, Arm9™ Core
|
|
|
|
|
|
|
|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quick reference to our documentation types
1-10 of 21 documents
Compact List
3 design files
Receive the full breakdown. See the product footprint and more in the eCad file.
Quick reference to our software types.
1-5 of 23 software files
Additional software available. View our featured partner solutions.
Note: For better experience, software downloads are recommended on desktop.
To get further assistance directly from NXP, please see our Engineering Services.
1-5 of 46 engineering services
To find additional partner offerings that support this product, visit our Partner Marketplace.
