High Side Switches

  • Facebook
  • Twitter
  • LinkedIn
  • Printer

NXP smart high side switches for automotive (12 V), bus/truck (24V) and industrial application are eXtreme switch devices. They belong to an expanding family designed to control, protect and diagnose various types of loads with enhanced precision in BCM, ECU or junction boxes. Typical loads are incandescent bulbs, light emitting diodes modules (LEDs) and DC motors. With on-resistance ranging from 2 mOhm to 50 mOhm in 1 to 5 channel configurations, these products combine flexibility, advanced protection and diagnostics through daisy chainable SPI for safe and robust designs.

  • Product
  • Hardware
  • Applications
Product Selector Cross Reference

Choosing the right product just got easier. View all product finder tools.

High Side Switches Family

12XS2

12 V multipurpose low RDSON extreme switch.

12XS6

External automotive lighting multi-channel extreme switch.

24XS4

24 V multipurpose low RDSON extreme switch.

32XSG

Industrial multipurpose 32 V SPI-controlled smart switch.

XS2410

Quad 100 mΩ / Dual 50 mΩ, 3.0 V to 60 V high-side switch.

Evaluation Boards and Reference Designs

NXP offers evaluation boards and reference designs that make secure edge solutions connected and efficient with innovative analog technologies. Start today.

  • Explore Hardware

Applications

Automotive

  • Battery Management System
  • Lighting
  • DC Motor Control
  • Relay / Fuse Replacement

Smart High Side Switches Fact Sheet

Smart high side switches combine flexibility through programmable SPI and robust designs through embedded protection, extended digital and analog feedback.
