BGU7258 WLAN LNA evaluation board

Roll over image to zoom in

Product Details

Supported Devices

RF

LNAs for WLAN

Features

  • The BGU7258 is optimized for the 5 GHz ISM-Band:
  • Fully integrated, high performance LNA with built-in bypass

Power Management

  • Exceptional 1.6 dB noise figure with 13 mA current consumption
  • Single supply 3.0 V to 3.6 V operation
  • Integrated concurrent 2.4 GHz notch filter and temperature stabilized bias network
  • High IP3i and low EVM
  • High ESD protection of 2 kV (HBM) on all pins
  • Small 0.5 mm pitch, 1.6 x 1.6 x 0.5 mm3 QFN-style package, MSL 1 at 260 ⁰C
  • Compliant to Directive 2002/95/EC, regarding Restriction of Hazardous Substances (RoHS) following NXP’s RHF-2006 indicator D (dark green)

Buy Options

OM7870-Image

Click to expand

  • OM7870

  • BGU7258 WLAN LNA evaluation board.

  • $160.00 USD
  • For a quantity of 1
    • Availability: In stock
    • Inventory: 21
    • Shipping: Normally ships 1-2 business days
Buy from NXP
