AMD/Xilinx FPGA Solution
NXP's power management solutions for AMD/Xilinx field-programmable gate array (FPGA) platforms help accelerate development for automotive, industrial, communications and edge computing applications with optimized power management integrated circuit (PMIC) and safety system basis chip (SBC) solutions, validated power architectures, reference power-tree designs and design resources.
Processor-specific power trees are available for Xilinx Zynq-7000, Zynq UltraScale+™ MPSoC (ZU2/ZU3, ZU4/ZU5/ZU6/ZU7/ZU9, ZU11/ZU15), Artix™-7, Artix™-7 High Performance, Spartan™ 7/8 and Kintex™ UltraScale™ platforms, each featuring the recommended NXP power solutions.
Application Details
Interactive Block Diagram
Interactive Block Diagram
For the best experience interacting with diagrams, please use a larger screen or maximize your browser window.
Select a block diagram:
Block Diagram
- FPGA Solution
System PMIC
-
MMPF0100:
14-Channel Configurable PMIC -
PF9455:
9-Channel PMIC for High-Performance Applications, Fit for up to SIL 2 -
PF09:
9-Channel PMIC for High-Performance Applications, ASIL D and SIL 2 -
PF9453:
PF9453 Low Power Multi Rail PMIC for i.MX 91, i.MX 93 and Simple Linux Platforms -
PF7100:
7-Channel Power Management Integrated Circuit for High Performance Applications, Fit for ASIL B Safety Level -
PF81-PF82:
12-Channel Power Management Integrated Circuit (PMIC) for High-Performance Processing Applications
Core PMIC
General PMIC
Designs
Reference Design
Multiprocessor Demo Board (BYLINK)
Enables system-level validation of multi-PMIC power architectures for FPGA platforms, supporting rapid prototyping and evaluation of power tree designs.
Reference Design
PMIC OTP Programming Board
Supports OTP configuration and programming of PMIC devices, enabling flexible evaluation and optimization of FPGA power management solutions.
Documentation
Quick reference to our documentation types
5 documents
Application Note (4)
Supporting Information (1)
-
NXP Power Solutions for AMD Xilinx FPGAs[NXP-POWER-SOLUTIONS-FOR-AMD-XILINX-FPGAS]
