The Smart Application Blueprint for Rapid Engineering (SABRE) for automotive infotainment offers a solid foundation for the next-generation infotainment, instrument cluster, telematics and rear seat entertainment designs.

Based on i.MX 6 series of applications processors, our scalable implementation of the Arm^® Cortex^®-A9 CPU cores
Single-, dual- and quad-core offerings, processing speeds up to 1 GHz, and a high level of automotive-specific integration, the SABRE for automotive infotainment enables customers to rapidly deploy today's consumer user experiences in the car

Design Files

Software

Product Details

Supported Devices

Processors and Microcontrollers

i.MX 6 Processors

i.MX6DL: i.MX 6DualLite Processors – Dual-Core, 3D Graphics, HD Video, Arm^® Cortex^®-A9 Core
i.MX6Q: i.MX 6Quad Processors - High-Performance, 3D Graphics, HD Video, Arm^® Cortex^®-A9 Core
i.MX6QP: i.MX 6QuadPlus Processor - Quad-Core, High-Performance, Advanced 3D Graphics, HD Video, Advanced Multimedia, Arm^® Cortex^®-A9 Core

Features

Processor

i.MX 6QuadPlus processor running up to 1 GHz, i.MX 6Quad processor running up to 1 GHz or i.MX 6Dual Lite processor running up to 800 MHz * i.MX 6QuadPlus, i.MX 6Quad and i.MX 6Dual Lite can be configured as an i.MX 6DualPlus, i.MX 6Dual, and i.MX 6Solo processor for lower CPU load applications

Connectivity

MIPI CSI interface
SD Card Interface
High-speed USB OTG interface
1.5 Gb/s SATA interface (i.MX 6Quad only)
Ethernet interface
MLB 150 INIC interface

Display

LVDS output
HDMI display interface

Memory

2 GB x 64 DDR3 running up to 532 MHz (1066 MHz DDR): i.MX 6Quad Plus and i.MX 6Quad CPU cards
2 GB x 64 DDR3 running up to 400 MHz (800 MHz DDR): i.MX 6Dual Lite CPU card
32 MB 16-bit parallel NOR flash
8-bit NAND flash socket

Debug

JTAG and UART interfaces

Connectivity

I²C module connector
De-serializer input for video/camera input
Triple video DAC with analog video inputs for video/camera input
Dual USB host connectors
GPS module connector (UART)
Bluetooth^® module connector (I²S + UART)
SD card interface (Wi-Fi^® modules or data cards)
MLB 25/50 INIC interface
Low and high-speed CAN interfaces

Display

Second LVDS output

Audio

Multichannel audio codec and I/O for up to eight channel outputs, one stereo line input, and two microphone inputs
Broadcast tuner module connector
Sirius/XM radio module connector
S/PDIF receive interface

Buy Options

MCIMXABASEV1
SABRE Automotive Platform, Hardware, i.MX 6Quad/6Dual/6DualLite/6Solo, Expansion Board.

$699.00 USD
For a quantity of 1
- Availability: In stock
- Inventory: 10
- Shipping: Normally ships 1-2 business days

Buy from NXPBuy From Distributor

Distributor Name	Region	Inventory	Inventory Date

Upon selection of a preferred distributor, you will be directed to their web site to place and service your order. Please be aware that distributors are independent businesses and set their own prices, terms and conditions of sale. NXP makes no representations or warranties, express or implied, about distributors, or the prices, terms and conditions of sale agreed upon by you and any distributor.

MCIMX6QAICPU2
SABRE Automotive Platform, Hardware, i.MX 6Quad/6Dual, No Display, No Camera.

$1299.00 USD
For a quantity of 1
- Availability: In stock
- Inventory: 5
- Shipping: Normally ships 1-2 business days

Buy from NXP

MCIMX6QPAICPU3
i.MX 6QuadPlus/DualPlus SABRE Automotive Platform CPU Card.

$799.00 USD
For a quantity of 1
- Availability: Pending stock

Buy from NXP

Documentation

Quick reference to our documentation types.

1-5 of 47 documents

^{Fact Sheet}
SABRE for Automotive Infotainment Based on the i.MX 6 Series - Fact SheetFeatured

PDFRev 2Mar 2, 2016197.3 KBIMX6SABREAIFSEnglish
^{Supporting Information}
IMX_O8.0.0_1.0.0_ANDROID_DOCSFeatured

GZRev O8.0.0_1.0.0Dec 13, 20197.4 MBIMX_O8.0.0_1.0.0_ANDROID_DOCSEnglish
Sign in required
^{User Guide}
SABRE AI for i.MX 6QuadPlus Quick Start GuideGetting Started

PDFRev 0Mar 3, 2016708.0 KBSABREAI6QDPLUSQSGEnglish
Sign in required
^{User Guide}
SABRE for Automotive Infotainment Based on the i.MX 6 Series - Quick Start GuideGetting Started

PDFRev 3Nov 20, 2014731.3 KBIMX6SABREINFOQSGEnglish
Sign in required
^{Release Note}
L5.10.72_2.2.3_LINUX_RN

PDFRev LF_L5.10.72_2.2.3Dec 8, 2022457.8 KBL5.10.72_2.2.3_LINUX_RNEnglish
Sign in required
^{Release Note}
L5.10.72_2.2.2_LINUX_RN

PDFRev LF_L5.10.72_2.2.2Jul 19, 2022458.1 KBL5.10.72_2.2.2_LINUX_RNEnglish
Sign in required
^{Release Note}
L5.4.70_2.3.3_LINUX_DOCS

PDFRev L5.4.70_2.3.3May 31, 2021373.7 KBL5.4.70_2.3.3_LINUX_DOCSEnglish
Sign in required
^{Release Note}
L5.4.70_2.3.1_LINUX_DOCS

PDFRev L5.4.70_2.3.1Mar 26, 2021358.8 KBL5.4.70_2.3.1_LINUX_DOCSEnglish
Sign in required
^{Release Note}
i.MX 6Quad, i.MX 6Dual, i.MX 6DualLite, i.MX 6Solo and i.MX 6Sololite Linux L3.10.17_1.0.3 - Release Notes.

PDFRev L3.10.17_1.0.3Oct 14, 2015236.6 KBIMX6YOCTOPATCHRNEnglish
^{Release Note}
i.MX 6 Yocto Project L3.14.28_1.0.1 Patch Release Notes - Release Notes

PDFRev 0May 15, 2015229.7 KBIMX6L31428101RNEnglish
^{Release Note}
i.MX 6Quad, i.MX 6Dual, i.MX 6DualLite, i.MX 6Solo and i.MX 6Sololite Linux BSP Documentation. Patch Release Notes

PDFRev L3.0.101_4.1.1.Nov 3, 201497.2 KBIMX6LXPATCHRNEnglish
Sign in required
^{Supporting Information}
L5.15.71_2.2.1_LINUX_DOC

ZIPRev LF_L5.15.71_2.2.1Jul 21, 2023887.0 KBL5.15.71_2.2.1_LINUX_DOCEnglish
Sign in required
^{Supporting Information}
L5.4.70_2.3.0_LINUX_DOCS

ZIPRev L5.4.70_2.3.0Jul 14, 202211.8 MBL5.4.70_2.3.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L5.15.5_1.0.0_LINUX_DOCS

ZIPRev LF_L5.15.5_1.0.0Jun 24, 202220.6 MBL5.15.5_1.0.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L5.10.72_2.2.0_LINUX_DOCS

ZIPRev LF_L5.10.72_2.2.0Dec 17, 2021L5.10.72_2.2.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L5.10.52_2.1.0_LINUX_DOCS

ZIPRev LF_L5.10.52_2.1.0Dec 15, 2021L5.10.52_2.1.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L5.10.35_2.0.0_LINUX_DOCS

ZIPRev LF_L5.10.35_2.0.0Dec 15, 202115.3 MBL5.10.35_2.0.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L5.10.9_1.0.0_LINUX_DOCS

ZIPRev LF_L5.10.9_1.0.0Apr 12, 202111.7 MBL5.10.9_1.0.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L5.4.47_2.2.0_LINUX_DOCS

ZIPRev L5.4.47_2.2.0Jan 26, 202111.6 MBL5.4.47_2.2.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
P9.0.0_2.2.0_DOCS

ZIPRev P9.0.0_2.2.0Nov 19, 20207.0 MBP9.0.0_2.2.0_DOCSEnglish
^{Supporting Information}
L5.4.24_2.1.0_LINUX_DOCS

ZIPRev L5.4.24_2.1.0Jul 22, 202011.5 MBL5.4.24_2.1.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L5.4.3_1.0.0_LINUX_DOCS

ZIPRev LF_L5.4.3_1.0.0Apr 7, 202011.2 MBL5.4.3_1.0.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L4.19.35_1.1.0_LINUX_DOCS

ZIPRev L4.19.35_1.1.0Dec 2, 201911.2 MBL4.19.35_1.1.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
IMX6_N7.1.1_1.0.0_ANDROID_DOCS

GZRev N7.1.1_1.0.0Jun 14, 20198.5 MBIMX6_N7.1.1_1.0.0_ANDROID_DOCSEnglish
Sign in required
^{Supporting Information}
IMX6_M6.0.1_1.0.0_ANDROID_DOCS

GZRev M6.0.1_1.0.0Jun 14, 20198.4 MBIMX6_M6.0.1_1.0.0_ANDROID_DOCSEnglish
Sign in required
^{Supporting Information}
IMX6_M6.0.1_2.1.0_ANDROID_DOCS

GZRev M6.0.1_2.1.0Jun 14, 20198.4 MBIMX6_M6.0.1_2.1.0_ANDROID_DOCSEnglish
Sign in required
^{Supporting Information}
L4.14.78_1.0.0_LINUX_DOCS

ZIPRev L4.14.78_1.0.0May 7, 201910.1 MBL4.14.78_1.0.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L4.14.98_2.0.0_LINUX_DOCS

ZIPRev L4.14.98_2.0.0May 7, 201910.2 MBimx-yocto-L4.14.98_2.0.0_gaEnglish
Sign in required
^{Supporting Information}
L4.9.88_2.0.0_LINUX_DOCS

GZRev L4.9.88_2.0.0May 30, 201810.0 MBL4.9.88_2.0.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L4.9.11_1.0.0_LINUX_DOCS

GZRev L4.9.11_1.0.0Sep 21, 201710.3 MBL4.9.11_1.0.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L4.1.15_2.0.0_LINUX_DOCS

GZRev L4.1.15_2.0.0Jan 18, 20178.8 MBL4.1.15_2.0.0-LINUX-DOCSEnglish
Sign in required
^{Supporting Information}
IMX6_L500_101_ANDROID_DOCS

GZRev L5.0.0_1.0.1Aug 31, 2016376.3 KBIMX6_L500_101_AND_DOCSEnglish
Sign in required
^{Supporting Information}
IMX6_KK443_201_ANDROID_DOCS

GZRev kk4.4.3_2.0.1Jul 15, 2016375.6 KBIMX6_KK443_201_ANDROID_DOCSEnglish
Sign in required
^{Supporting Information}
L4.1.15_1.1.0_LINUX_DOCS

GZRev L4.1.15_1.1.0Apr 20, 20168.9 MBL4.1.15_1.1.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L4.1.15_1.0.0_LINUX_DOCS

GZRev L4.1.15_1.0.0Mar 31, 20168.9 MBL4.1.15_1.0.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L3.14.28_1.0.0_LINUX_DOCS

GZRev L3.14.28_1.0.0Feb 5, 20169.2 MBL3.14.28_1.0.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
L3.14.52_1.1.0_LINUX_DOCS

GZRev L3.14.52_1.1.0Feb 5, 20169.0 MBL3.14.52_1.1.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
IMX6_L5.1.1_2.1.0_ANDROID_DOCS

GZRev L5.1.1_2.1.0Jan 15, 20168.6 MBIMX6_L5.1_2.1.0_ANDROID-DOCSEnglish
Sign in required
^{Supporting Information}
i.MX6 Android L5.0.0_1.0.0 BSP Documentation

GZRev L5.0.0_1.0.0Jul 1, 20158.4 MBIMX6_L500_100_ANDROID_DOCSEnglish
Sign in required
^{Supporting Information}
i.MX 6Quad, i.MX 6Dual, i.MX 6DualLite, i.MX 6Solo and i.MX 6Sololite Linux BSP Documentation. Includes Release Notes, Reference Manual, User guide. API Documentation. Linux Multimedia Codecs Documentation. Includes CODECs Release Notes and User's Guide.

GZRev L3.10.53_1.1.0Apr 13, 20159.0 MBL3.10.53_1.1.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
i.MX6 Android kk4.4.3_2.0.0 BSP Documentation

GZRev kk4.4.3_2.0.0Feb 6, 20157.8 MBIMX6_KK443_200_ANDROID_DOCSEnglish
Sign in required
^{Supporting Information}
i.MX 6Quad, i.MX 6Dual, i.MX 6DualLite, i.MX 6Solo and i.MX 6Sololite Android BSP Documentation

GZRev JB4.3.0_1.1.1.Oct 24, 201477.7 KBIMX6_JB43_111_ANDROID_DOCSEnglish
Sign in required
^{Supporting Information}
i.MX6 Android kk4.4.2_1.0.0 BSP Documentation

GZRev KK4.4.2_1.0.0Jul 14, 20143.1 MBIMX6_KK442_100_ANDROID_DOCSEnglish
Sign in required
^{Supporting Information}
Linux 3.10.17 BSP and MM Bundle

GZRev L3.10.17_1.0.0May 8, 201410.2 MBL3.10.17_1.0.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
i.MX 6Quad, i.MX 6Dual, i.MX 6DualLite, i.MX 6Solo and i.MX 6Sololite Android jb4.3_1.1.0 BSP Documentation. Includes Release Notes, User's Guide, QSG and FAQ Sheet.

GZRev jb4.3_1.1.0Dec 20, 20132.5 MBIMX6_JB43_110_ANDROID_DOCSEnglish
Sign in required
^{Supporting Information}
i.MX 6Quad, i.MX 6Dual, i.MX 6DualLite, i.MX 6Solo and i.MX 6Sololite Linux BSP Documentation. Includes Release Notes, Reference Manual, User guide. API Documentation

GZRev L3.0.35_4.1.0Sep 11, 201315.5 MBL3.0.35_4.1.0_LINUX_DOCSEnglish
Sign in required
^{Supporting Information}
i.MX 6Quad, i.MX 6Dual, i.MX 6DualLite, i.MX 6Solo and i.MX 6Sololite Linux Multimedia Codecs Documentation. Includes CODECs Release Notes and User's Guide

GZRev L3.0.35_4.1.0Sep 5, 2013859.2 KBL3.0.35_4.1.0_LINUX_MMDOCSEnglish
Sign in required

Show All

Design Resources

Design Files

5 design files

^{Printed Circuit Boards and Schematics}
Design files for Base Board

ZIPRev E4Oct 12, 2016 00:00:008.5 MBSABRE-AI-BASE-BOARD
Sign in required

Download
^{Printed Circuit Boards and Schematics}
Design files for i.MX 6Quad, i.MX 6DualLite CPU2 Cards with AVB

ZIPRev F, BMar 23, 2016 00:00:0025028 KBSABRE_AI_DESIGNFILES_CPU2
Sign in required

Download
^{Printed Circuit Boards and Schematics}
Design files for i.MX 6QuadPlus CPU3 Card with AVB

ZIPRev AMar 2, 2016 00:00:0022.9 MBi.MX6QP_SABRE_AI_DESIGNFILES
Sign in required

Download
^{Printed Circuit Boards and Schematics}
Design files for ENET Daughter Card with Atheros PHY

ZIPRev DMar 23, 2016 00:00:004.7 MBENET_CARD_ATH_PHY_DESIGNFILES
Sign in required

Download
^{Printed Circuit Boards and Schematics}
Design files for i.MX 6Quad and i.MX 6DualLite CPU1 Cards

ZIPRev 1.0.2May 19, 2014 00:00:0033.7 MBi.MX6_SABRE_AI_CPU1_DESIGNFILES
Sign in required

Download
