Features

Processor

MIMXRT685SFVKB

Cortex-M33 running up to 300 MHz
Cadence^® Tensilica^® HiFi 4 running up to 600 MHz
VFBGA 176 package

Board Memory

Macronix Octal Flash
AP Memory PSRAM

Debug Capabilities

10-pin and 20-pin JTAG/SWD connectors supporting external debug/trace probes
On-board debug probe, with VCOM and CMSIS-DAP or J-link firmware options

Expansion Connectors

Arduino expansion
PMOD expansion
Expansion connector for 8-channel microphone board
I3C header
Flexcomm header

User Interface

Reset and User buttons for easy testing of software functionality
User LEDs

Connectivity

High/full-speed USB port with micro-A/B connector for the host or device functionality
SD Card slot

Sensors

NXP FXOS8700CQ accelerometer

Note: FXOS8700CQ accelerometer is in “End of Life” status

Audio and Voice

Dual Knowles SPH0641lM4H digital microphone
Stereo audio codec with Audio Line In/Out
Dual class D amplifiers with speaker connectors

Buy Options
