UCODE® DNA: UHF Tag IC for Secure Authentication

SL3S5002N0FUD

Click over video to play

Product Details

Select a section:

Features

Key Features

  • Read sensitivity -19 dBm
  • AES authentication sensitivity -18 dBm
  • Write sensitivity -11 dBm
  • Encoding speed: 32 bits per 1.5 milliseconds
  • Standard functionalities
    • Tag Power Indicator
    • Automatic self pre-serialization for 96-bit EPC
    • Integrated Product Status Flag (PSF)
    • Parallel encoding mode: >100 items in 60 ms
  • GS1 UHF RFID Gen2 v2.0 (Annex N, Tag Alteration (Authenticate))
  • ISO/IEC 29167-10
  • Compatible with single-slit antenna

Memory

  • 224-bit of EPC memory
  • Supports self pre-serialization for 96-bit EPC
  • 96-bit Tag IDentifier (TID) factory locked
  • 48-bit serial number factory-encoded into TID
  • Up to 3kbit User Memory (3072 bits) with BlockPermalock (depending on IC version and configuration)
  • 32-bit kill password to permanently disable the tag
  • 32-bit access password
  • Wide operating temperature range: -40 °C up to +85 °C
  • Minimum 100,000 write cycle endurance
  • Data retention 20 years

End user benefit

  • Tag authentication based on cryptographic security
  • Privacy protection based on cryptographic security
  • Long read/write ranges due to leading edge chip sensitivity
  • Hassle-free deployment even without significant security knowhow and even without secure backend infrastructure due to NXP’s Trust Provisioning service offering
  • Reliable operation in dense reader and noisy environments through high interference rejection

Antenna design benefits

  • High sensitivity enables smaller and cost efficient antenna designs
  • Selected chip impedance enables re-use of antenna designs from UCODE 7

Label / module manufacturer benefit

  • Large RF pad-to-pad distance to ease antenna design
  • Symmetric RF inputs are less sensitive to process variation
  • Single-slit antenna for a more mechanically stable antenna connection
  • Automatic self pre-serialization of the 96-bit EPC
  • Extremely fast encoding of the EPC content
