i.MX 8XLite Applications Processors for Telematics, V2X and Industrial Control
iMX8XLite Receive alerts
- Preproduction
- This page contains information on a preproduction product. Specifications and information herein are subject to change without notice. For additional information contact support or your sales representative.
Extending the scalable range of the i.MX 8 series, the i.MX 8XLite family is composed of common subsystems and architecture from the higher-end i.MX 8X family, establishing a range of cost-performance scaling and high levels of software reuse. Supported with an expansive software ecosystem and dedicated Hardware Security Modules to enable telematics solutions and vehicle-to-everything (V2X) applications with a single processor while retaining efficient performance.
i.MX 8XLite applications include vehicle telematics, vehicle-to-vehicle (V2V) and vehicle-to-infrastructure (V2I) solutions, road infrastructure connectivity, industrial equipment and building control.
Product Details
Features
Processor Complex
- 2x-1x Arm® Cortex®-A35 cores
- 1x Cortex-M4F core for real-time processing
Memory
- 16-bit DDR3L-1866 and LPDDR4-2400
- 1x FlexSPI for fast boot from SPI NOR flash
- 2x SD 3.0 card interfaces
- 1x eMMC5.1/SD3.0
- NAND (62-bit ECC support)
-
ECC Capabilities
- Cortex-A35 L1 cache parity
- Cortex-A35 L2 cache ECC
- ECC Protection on DDR interface
Connectivity
- 2x USB 2.0
- 1x 1Gb Ethernet with AVB
- 1x 1Gb Ethernet with TSN
- 3x CAN / CAN FD
- 4x UART, 1x UART (Cortex M4F Dedicated)
- PCIe 3.0 (1-lane) with L1 substate
- 1x ADC converter (6-channels)
- 4x LPSPI, 4x SAI, 1x ASRC, 4x PWM
- 4x I2C (High-speed), 1x I2C (Cortex M4F Dedicated)
- 1x SPDIF
Security
- High Assurance Boot, SHE
- TRNG, AES-128, AES-256, 3DES, ARC4, RSA4096, SHA-1, SHA-2, SHA-256, MD-5
- RSA-1024, 2048, 3072, 4096 and secure key storage
- Tamper-pins
- Inline Encryption Engine (AES-128)
- V2X Optimized High Security Module (HSM)
Temperature
- Automotive: -40° to 125° C Tj (AEC-Q100 Grade 2)
- Industrial: -40° to 105° C Tj
Advanced Power Management
- Recommended PMIC: PF7100 power management integrated circuit for i.MX 8XLite family.
