QorIQ® P1010 Reference Design Board

P1010RDB Active

Roll over image to zoom in

The NXP® P1010 RDB is a highly integrated reference design board that can help shorten your time to market. The reference design is aimed at low-cost networking applications (with or without trust architecture), wired and wireless access, industrial, and smart energy applications.

Product Details

Features

Memory

  • 1 GB DDR3

Connectivity

  • 2x PCI Express®
  • 2x SATA
  • 3x Gb Ethernet ports
  • TDM interface to SLIC for VoIP applications
  • 2X FlexCAN interfaces for industrial protocol developing

Size

  • Mini ITX form factor

Support

  • Supports trust architecture

Buy Options

P1010RDB-PB-Image

Click to expand

  • P1010RDB-PB
    Active

  • QorIQ P1010/14 Reference Design Board.

  • $626.75 USD
  • For a quantity of 1
    • Availability: Pending Stock
ADD TO CART
Order from distributors
