MCIMX6UL-EVK: i.MX6UltraLite Evaluation Kit

Overview

i.MX 6UltraLite Evaluation Kit
i.MX 6UltraLite Evaluation Kit

i.MX 6UltraLite Evaluation Kit

Getting Started i.MX 6UltraLite EVK

Getting Started i.MX 6UltraLite EVK

Getting Started with i.MX 6UltraLite EVK

Getting Started with i.MX 6UltraLite EVK

Specifications

Supported Devices

Processors and Microcontrollers

i.MX 6 Processors
  • i.MX6UL : i.MX 6UltraLite Processor - Low-power, Secure, Arm® Cortex®-A7 Core

Products

  • MAG3110 : High Accuracy, 3D Magnetometer

Sensors

Accelerometers
  • FXLS8471Q : ±2g/±4g/±8g, Low g, 14-Bit Digital Accelerometer

MoreLess

Technical and Functional Specifications

Processor i.MX 6UltraLite 696 MHz Arm® Cortex®-A7 core
Discretes
Memory
  • 4 Gb DDR3L SDRAM, 400 MHz
  • 256 MB Quad SPI Flash
  • MicroSD connector
  • Footprint for eMMC
  • Footprint for NAND Flash
Size 2.66 inch x 1.27 inch (6.76 cm x 4.24 cm), 4-layer board
Display board interface
  • LCD expansion port connector
  • HDMI connector and footprint for HDMI transmitter
Audio
  • Audio codec
  • 3.5 mm Stereo Headphone output
  • Mono-Microphone input on board
  • Left and Right Speaker Out connectors
Connectivity
  • One USB 2.0 Micro-B OTG connectors
  • One USB 2.0 Standard-A host connectors
  • Two Ethernet (10/100T) connectors
  • Dual CAN connector
  • SD/SDIO connector
Camera Parallel camera connector
Sensors
  • NXP® MAG3110 eCOMPASS
  • NXP FXLS8471Q accelerometer
  • Footprint for gyroscope
Debug
  • 20-pin standard JTAG connector
  • UART to Micro USB connector
Expansion port Arduino® header
Size 5.12 inch x 4.25 inch (13.0 cm x 10.8 cm), 4-layer board

Buy

  • MCIMX6UL-EVK   No Longer Manufactured

  • MCIMX6UL-EVK
    • MCIMX6UL-EVKB (CPU board and base board)
MCIMX6UL-EVK-Image
    • LCD8000-43T
    • 1 @ US
    • $100.00
    • Use Coupon
    • Distributor

    Don't have an NXP coupon? You can purchase this product from one of our authorized distributors.

  • MCIMX6UL-EVKB   Active

  • i.MX 6UltraLite Evaluation Kit
    • 1 @ US
    • $149.00
      • Use Coupon
      • Distributor

        • Don't have an NXP coupon? You can purchase this product from one of our authorized distributors.

MCIMX6UL-EVKB-Image
1579109330588723448640

Design Resources

Get Started

Documents   ( 24 )

Design Resources   ( 1 )

Software   ( 33 )

Documents

User Guide  ( 3 )

  • i.MX 6UltraLite EVK - Quick Start Guide

    The i.MX 6 UltraLite evaluation kit (EVK) introduces developers
to the i.MX 6UltraLite applications processor. To speed up development, the hardware design files, tools and board support packages (BSP) for Linux operating system are available. Some peripheral boards work with the i.MX 6UltraLite EVK to provide additional capabilities such as resistive touch display, EMV and Bluetooth connectivity. Refer to nxp.com/IMX6ULEVK
for further information.

    • PDF
    • Rev 4
    • Jun 26, 2017
    • 299.4 KB
    • IMX6ULTRALITEQSG
    • English,

    i.MX 6UltraLite EVK - 快速入门指南

    • PDF
    • Rev 0
    • 299.4 KB
    • IMX6ULTRALITEQSG

  • i.MX 6 Series USB Certification Guide

    The purpose of this document is to describe how to perform the USB Certification Test on the i.MX 6 series family of application processors. This document contains the description of procedures, tools, and criteria for the USB Compliance Test.

    • PDF
    • Rev 1
    • Feb 1, 2017
    • 6.4 MB
    • IMXUSBCGUG
    • English

  • i.MX 6UltraLite EVK Board Hardware User's Guide

    Semiconductor i.MX 6UltraLite Applications Processor. This board is fully supported by NXP Semiconductors. This Manual includes system setup and debugging, and provides detailed information on the overall design and usage of the EVK board from a Hardware Systems perspective.This document is the Hardware User Guide for the i.MX 6UltraLite Evaluation Kit (EVK) based on the NXP

    • PDF
    • Rev 1
    • Mar 30, 2016
    • 776.8 KB
    • IMX6ULEVKHUG
    • English

Fact Sheet  ( 3 )

  • i.MX 6ULL Application Processor Fact Sheet

    The i.MX 6ULL EVK is a highly flexible, market-focused development tools based on the i.MX 6ULL processor.

    • PDF
    • Rev 5
    • Sep 27, 2019
    • 301.2 KB
    • EVKIMX6ULFS
    • English,

    基于i.MX 6Ultra Lite的评估套件 - 简介

    • PDF
    • Rev 0
    • 301.2 KB
    • EVKIMX6ULFS

  • i.MX 6UltraLite - Fact Sheet

    Expanding the i.MX 6 series, the i.MX 6UltraLite is a high performance,
ultra-efficient processor family featuring an advanced implementation of a single Arm® Cortex®-A7 core, which operates at speeds up to 528 MHz.

    • PDF
    • Rev 5
    • Mar 3, 2016
    • 252.9 KB
    • IMX6ULTRALITEFS
    • English,

    i.MX 6UltraLite - 简介

    • PDF
    • Rev 0
    • 252.9 KB
    • IMX6ULTRALITEFS

  • i.MX 6 Series of Applications Processors Fact Sheet

    The i.MX 6 series of applications processors unleashes a scalable multicore platform that includes single-, dual- and quad-core families based on the Arm® Cortex®-A9 architecture, in addition to the i.MX 6SoloX which offers heterogeneous multicore processing with the Cortex®-A9 and Cortex®-M4 cores to deliver solutions with low power consumption, fast response time and system integrity.

    • PDF
    • Rev 15
    • Jun 14, 2017
    • 314.9 KB
    • IMX6SRSFS
    • English,

    i.MX 6系列应用处理器 - 简介

    • PDF
    • Rev 5
    • 314.9 KB
    • IMX6SRSFS

Release Note  ( 2 )

  • L5.4.70_2.3.1_LINUX_DOCS

    i.MX L5.4.70_2.3.1-patch Release Notes

    • PDF
    • Rev L5.4.70_2.3.1
    • Mar 26, 2021
    • 358.8 KB
    • L5.4.70_2.3.1_LINUX_DOCS
    • English

  • L5.4.70_2.3.3_LINUX_DOCS

    i.MX L5.4.70_2.3.3-patch Release Notes

    • PDF
    • Rev L5.4.70_2.3.3
    • May 31, 2021
    • 373.7 KB
    • L5.4.70_2.3.3_LINUX_DOCS
    • English

Supporting Information  ( 16 )

  • L4.14.98_2.0.0_LINUX_DOCS

    L4.14.98_2.0.0 for Linux BSP Documentation. Includes Release Notes, User Guide.

    • ZIP
    • Rev L4.14.98_2.0.0
    • May 7, 2019
    • 10.2 MB
    • imx-yocto-L4.14.98_2.0.0_ga
    • English

  • L5.4.24_2.1.0_LINUX_DOCS

    i.MX L5.4.24_2.1.0 for Linux BSP Documentation. Includes Release Notes, User Guide.

    • ZIP
    • Rev L5.4.24_2.1.0
    • Jul 22, 2020
    • 11.5 MB
    • L5.4.24_2.1.0_LINUX_DOCS
    • English

  • L5.4.3_1.0.0_LINUX_DOCS

    i.MX L5.4.3_1.0.0 for Linux BSP Documentation. Includes Release Notes, User Guide.

    • ZIP
    • Rev LF_L5.4.3_1.0.0
    • Apr 7, 2020
    • 11.2 MB
    • L5.4.3_1.0.0_LINUX_DOCS
    • English

  • L4.1.15_2.0.0_LINUX_DOCS

    i.MX 6QuadPlus, i.MX 6Quad, i.MX 6DualPlus, i.MX 6Dual, i.MX 6DualLite, i.MX 6Solo, i.MX6SoloX, i.MX 6Sololite, iMX 6UltraLite, iMX 7Dual and iMX 6UltraLiteLite Linux BSP Documentation. Includes Release Notes, Reference Manual, User guide.

    • GZ
    • Rev L4.1.15_2.0.0
    • Jan 18, 2017
    • 8.8 MB
    • L4.1.15_2.0.0-LINUX-DOCS
    • English

  • L5.10.52_2.1.0_LINUX_DOCS updated

    i.MX L5.10.52_2.1.0 for Linux BSP Documentation. Includes Release Notes, User Guide.

    • ZIP
    • Rev LF_L5.10.52_2.1.0
    • Nov 2, 2021
    • L5.10.52_2.1.0_LINUX_DOCS
    • English

  • L5.4.70_2.3.0_LINUX_DOCS

    i.MX L5.4.70_2.3.0 for Linux BSP Documentation. Includes Release Notes, User Guide.

    • ZIP
    • Rev L5.4.70_2.3.0
    • Jan 26, 2021
    • 11.7 MB
    • L5.4.70_2.3.0_LINUX_DOCS
    • English

  • L4.14.78_1.0.0_LINUX_DOCS

    L4.14.78_1.0.0 for Linux BSP Documentation. Includes Release Notes, User Guide.

    • ZIP
    • Rev L4.14.78_1.0.0
    • May 7, 2019
    • 10.1 MB
    • L4.14.78_1.0.0_LINUX_DOCS
    • English

  • L5.10.35_2.0.0_LINUX_DOCS

    i.MX L5.10.35_2.0.0 for Linux BSP Documentation. Includes Release Notes, User Guide.

    • ZIP
    • Rev LF_L5.10.35_2.0.0
    • Jun 29, 2021
    • 15.3 MB
    • L5.10.35_2.0.0_LINUX_DOCS
    • English

  • L3.14.38_6ul_LINUX_DOCS

    i.MX 6UltraLite Linux BSP Documentation. Includes Release Notes, Reference Manual, User guide, API Documentation.

    • GZ
    • Rev L3.14.38_6ul
    • Sep 9, 2015
    • 3.4 MB
    • L3.14.38_6UL_LINUX_DOCS
    • English

  • L4.1.15_1.0.0_LINUX_DOCS

    i.MX 6QuadPlus, i.MX 6Quad, i.MX 6DualPlus, i.MX 6Dual, i.MX 6DualLite, i.MX 6Solo, i.MX6SoloX, i.MX 6SoloLite and iMX 6UltraLite Linux BSP Documentation. Includes Release Notes, Reference Manual, User guide. API Documentation. Linux Multimedia Codecs Documentation. Includes CODECs Release Notes and User's Guide.

    • GZ
    • Rev L4.1.15_1.0.0
    • Mar 31, 2016
    • 8.9 MB
    • L4.1.15_1.0.0_LINUX_DOCS
    • English

  • L4.9.11_1.0.0_LINUX_DOCS

    L4.9.11_1.0.0 for Linux BSP Documentation. Includes Release Notes, User Guide.

    • GZ
    • Rev L4.9.11_1.0.0
    • Sep 21, 2017
    • 10.3 MB
    • L4.9.11_1.0.0_LINUX_DOCS
    • English

  • L5.10.9_1.0.0_LINUX_DOCS

    i.MX LF_L5.10.9_1.0.0 for Linux BSP Documentation. Includes Release Notes, User Guide.

    • ZIP
    • Rev LF_L5.10.9_1.0.0
    • Apr 12, 2021
    • 11.7 MB
    • L5.10.9_1.0.0_LINUX_DOCS
    • English

  • L4.1.15_1.1.0_LINUX_DOCS

    i.MX 6QuadPlus, i.MX 6Quad, i.MX 6DualPlus, i.MX 6Dual, i.MX 6DualLite, i.MX 6Solo, i.MX6SoloX, i.MX 6Sololite and iMX 6UltraLite Linux BSP Documentation. Includes Release Notes, Reference Manual, User guide. API Documentation. Linux Multimedia Codecs Documentation. Includes CODECs Release Notes and User's Guide.

    • GZ
    • Rev L4.1.15_1.1.0
    • Apr 20, 2016
    • 8.9 MB
    • L4.1.15_1.1.0_LINUX_DOCS
    • English

  • L4.19.35_1.1.0_LINUX_DOCS

    L4.19.35_1.1.0 for Linux BSP Documentation. Includes Release Notes, User Guide.

    • ZIP
    • Rev L4.19.35_1.1.0
    • Dec 2, 2019
    • 11.2 MB
    • L4.19.35_1.1.0_LINUX_DOCS
    • English

  • L4.9.88_2.0.0_LINUX_DOCS

    L4.9.88_2.0.0 for Linux BSP Documentation. Includes Release Notes, User Guide.

    • GZ
    • Rev L4.9.88_2.0.0
    • May 30, 2018
    • 10.0 MB
    • L4.9.88_2.0.0_LINUX_DOCS
    • English

  • L5.4.47_2.2.0_LINUX_DOCS

    i.MX L5.4.47_2.2.0 for Linux BSP Documentation. Includes Release Notes, User Guide.

    • ZIP
    • Rev L5.4.47_2.2.0
    • Jan 26, 2021
    • 11.6 MB
    • L5.4.47_2.2.0_LINUX_DOCS
    • English
