i.MX 8ULP-CS Cloud Secured Applications Processors

i.MX8ULP-CS
  • Preproduction
  • This page contains information on a preproduction product. Specifications and information herein are subject to change without notice. For additional information contact support or your sales representative.

Roll over image to zoom in

Product Details

Select a section:

Block Diagram

i.MX 8ULP-CS Cloud Secured Applications Processor

i.MX 8ULP-CS Cloud Secured Applications Processor

Features

CPU

  • Arm® Cortex®-A35 @ 1.0 GHz
  • Arm Cortex-M33 @ 216 Mhz
  • Cadence® Tensillica® Fusion DSP @200 MHz for low-power voice and sensor hub processing
  • Pluton enabled secure enclave
  • RISC-V powered Power Management Subsystem (µpower)

Memory

  • Up to 896 KB total on-chip SRAM

External Memory

  • LPDDR3/LPDDR4/LPDDR4X
  • SPI-NOR
  • SPI-NAND

Connectivity

  • 10/100 Ethernet
  • FlexCAN

Display/Camera

  • 1x MIPI DSI (2-lane) with PHY
  • Up-to 24-bit RGB (DBI/DPI)
  • 1x MIPI CSI (2-lane) with PHY

Packaging

  • FCBGA 9.4 X 9.4 mm2
  • MAPBGA 15 x 15 mm2

Temperature Range

  • -40 °C – 105 °C

EdgeLock® Secure Enclave

EdgeLock Secure Enclave

Building on its strong history of providing turnkey security solutions, NXP introduces the EdgeLock secure enclave, a pre-configured security subsystem that simplifies implementation of complex security technologies and helps designers avoid costly errors.
