ColdFire+ Jx Family
The ColdFire+® MCF51Jx portfolio is defined by three families that scale from 32 KB to 256 KB of flash with innovative FlexMemory, configurable embedded EEPROM. Featuring ultra-low-power capabilities in small 5 x 5 mm footprint packages, the MCF51Jx family also offers a rich combination of peripherals including USB on-the-go (OTG), a serial audio interface, high-accuracy analog, hardware encryption, an integrated touch-sensing interface and more. These features make the 32-bit MCU sa highly integrated, cost-effective 32-bit solution for consumer and industrial applications. To maximize code re-use and shorten development time and investment, several of the ColdFire+ families are software and pin compatible. The ColdFire+ MCF51JF and MCF51JU families are software and pin compatible with each other as well as the ColdFire+ MCF51QF, MCF51QU, MCF51QH and MCF51QM families.
Product Details
Features
- Innovative FlexMemory configurable EEPROM
- Up to 10 flexible ultra-low-power modes
- Crypto acceleration unit and random number generator for secure communication
- Integrated capacitive touch sensing and display support via for low-power touch-sensing interface (TSI); (for JF, JU only)
- Small foot print packages designed for space-constrained application
- Integrated USB 2.0 full-speed device/host/OTG Controller supports connection via USB and battery charging
- Serial audio interface provides direct interface to codecs and to Inter-IC sound (I²S) audio devices
- Complimentary MQX Software Solutions
- This product is included in Our product longevity program, with assured supply for a minimum of 10 years after launch (for JF, JU only)
