MCX A34 Mixed-Signal, Optimized for Motor Control and High-Performance Analog Peripherals
The MCX A34 family of Mixed-Signal MCUs, including the MCX A345, MCX A346, MCXA343, and MCXA344, is purpose-built for motor control applications. Powered by high-performance Arm® Cortex®-M33 cores running up to 180 MHz, these devices offer flexible memory configurations ranging from 256KB to 1MB Flash and 64KB to 256KB RAM. Optimized with the MAU engine, the MCX A34 MCUs integrate 2x FlexPWM modules with 4 submodules, AOI, and up to 4x ADCs, depending on the device. They also feature a rich set of serial peripherals, including SmartDMA, to support complex control and communication needs.
All devices in the family are supported by the MCUXpresso Developer Experience, which streamlines development and accelerates time-to-market for embedded systems.
Product Details
Block Diagram
Choose a diagram:
Features
Core Platform
- Arm® Cortex®-M33 180 MHz
Processing Accelerators
- MAU (Math Accelerate Unit), supports trigonometric, reciprocal, square, square root, sine, cosine and arctan algorithms
- SmartDMA, co-processor for applications such as parallel camera interface and keypad scanning
Memory
-
Single-bank flash
- Up to 256 KB Flash with ECC (support one bit correction and two bits detection)
- Cache engine with 8 kB RAM
- Up to 64 KB RAM of which 8 KB is shared with cache, configurable as up to 8 KB RAM with ECC (support one bit correction and two bits detection)
- All RAM can be retained down to deep power Down mode
- ROM
Peripherals
- Analog
- 2x 16-bit ADC
- Up to 3 Msps in 16-bit mode, and 3.75 Msps in 12-bit mode
- Up to 39 ADC input channels total (depending on the package)
- Integrated temperature sensor
- 3x High-speed Comparators with 8 input pins and 8-bit DAC as internal reference
- 1x LPCMP is functional down to deep power down mode
- 3 x high-speed comparators with 8 input pins and 8-bit DAC as internal reference
- 1 x LPCMP is functional down to deep power down mode
- 3x OPAMP without PGA
- Advanced Motor Control Subsys
- Up to 2x FlexPWM each with 4 submodules, providing 16 complementary outputs of PWM (no Nanoedge module)
- Up to 2x Quadrature Encoder/Decoder (eQDC)
- 2x AOI (AND/OR/Invert) module support up to 4 output trigger
- Timers
- 3 x 32-bit standard general-purpose asynchronous timers/counters, which support up to four capture inputs and four compare outputs, PWM mode, and external count input. Specific timer events can be selected to generate DMA requests
- Low power timer
- Frequency measurement timer
- Windowed watchdog timer
- Wake timer
- Micro-tick timer (UTICK)
- OS event timer
- RTC timer without external 32KHz input
- Communication Interfaces for Connectivity
- 2x LPSPI, 2x LPI2C, 4x LPUART
- 1x FlexCAN with FD
Security
- 128-bit Universal Unique Identifier (UUID) per device in accordance with IETF's RFC4122 version5 specification
- Device lifecycle management
- Flash read/write/execute permission protect by MBC and lockable
- Implicit-protected flash region (IFR)
- Security monitoring
- Code Watchdog for code flow integrity checking
- GLIKEY enhances protection against attacks to gain unauthorized access to sensitive registers
Packaging
- LQFP100 14x14mm, LQFP64 10x10mm, LQFP48 7x7mm, QFN32 5x5mm
MCUXpresso Developer Experience
-
MCUXpresso ecosystem support
- Selection of IDE choices
- Pin, clock, peripheral, security and memory config tools
- Security programming and provisioning tools
- Software development kit (SDK)
- Zephyr™ RTOS support
