i.MX 8M Family - Arm® Cortex®-A53, Cortex-M4, Audio, Voice, Video
Overview
Features
Features
Multicore Processing
- Quad Arm® Cortex®-A53; Cortex®-M4F
GPU
- OpenGL/ES 3.1, OpenGL 3.0, Vulkan, OpenCL 1.2
Dual independent display interfaces
- MIPI-DSI (4-lanes); HDMI 2.0a
Video Playback
- 4Kp60 with High Dynamic Range (h.265, VP9), 4Kp30 (h.264), 1080p60 (MPEG2, MPEG4p2, VC1, VP8, RV9, AVS/AVS+, h.263, DiVX), MJPEG - 8x8
Audio
- 6x I2S/SAI (20+ channels, each 32-bits @384 KHz); SPDIF Tx/Rx; DSD512
Dual Camera Interfaces
- MIPI-CSI (4-lanes each)
External Memory Interfaces
- LPDDR4, DDR4, DDR3L; Quad SPI with XIP
USB
- Dual USB 3.0 Type C with PHY
PCIe
- Dual PCIe with L1 substates for fast wake-up from low power mode
Ethernet
- Gigabit Ethernet controller supporting AVB and EEE
Operating Systems
- Linux® OS, Android™, FreeRTOS
Temperature
- Consumer (0°C to 95°C Tj); Industrial (-40°C to 105°C Tj)
Package
- FCBGA, 0.65 mm pitch
i.MX 8M Block Diagram
Dual Displays with i.MX 8M Evaluation Kit
Getting Started with the i.MX 8M Evaluation Kit
Sound Bar and AV Receiver Solution Powered by i.MX 8M EVK
NXP Smart Home
i.MX 8-based Neural Networks for Object Recognition
-
i.MX 8M Block Diagram
-
Dual Displays with i.MX 8M Evaluation Kit -
Getting Started with the i.MX 8M Evaluation Kit -
Sound Bar and AV Receiver Solution Powered by i.MX 8M EVK -
NXP Smart Home -
i.MX 8-based Neural Networks for Object Recognition
i.MX 8M Block Diagram
Development Boards
Development Boards
MCIMX8M-EVK:
Evaluation Kit for the i.MX 8M Applications ProcessorTarget Applications
- Streaming video devices – over-the-top (OTT) set-top boxes, digital media adapters, digital signage, machine visual inspection
- Streaming audio devices – surround sound, wireless or networked speakers, sound bars, audio/video (AV) receivers, public address systems
- Voice control and voice assistants
- General purpose human-machine interface (HMI) solutions − touch, voice, graphics, video, image analytics, vision, sensors
